63kv 66kv Oil Immersed Power Transformer

The 66kV power transformer is a medium- and high-voltage power transmission and distribution transformer designed and manufactured in strict accordance with GB and IEC standards. It utilizes oil-immersed insulation and cooling technology, using natural cooling, air cooling, water cooling, or forced oil circulation to ensure stable operation under various loads. Its core structure includes key components such as the core, windings, oil tank, oil pillow, radiator, insulating bushing, tap changer, and gas relay. Through comprehensive optimized design and precision manufacturing, it achieves a significant leap in product performance.

66kv Transformer Parameters

TSTY Transformer Manufacturing Advantages

Silicon steel sheet: Use the best silicon steel sheets from Baosteel and Wuhan Iron and Steel in China, with high quality, high permeability and low loss;

Conductive rod: Highly conductive H62 material, effectively reducing heat generation and ensuring equipment stability;

Insulation system: New mineral insulating oil, enhanced insulation/extended life;

Tansformer box: Made of national standard high-quality steel plate profile, mechanical strength ≥345MPa, durable life >30 years.

Customized service: National project experience-- Leading the Hong Kong-Zhuhai-Macao Bridge, Hainan Free Trade Port and other projects, serving 20+ national power grid projects around the world (Southeast Asia/Middle East/Africa/Central Asia/Europe).

After-sales service guarantee: Professional operation and maintenance-- Multilingual 24-hour hotline + online platform, video installation instructions available, a team of certified engineers provides inspections, predictive maintenance and fault repairs.

Body Assembly: Utilizes integrated laminated wood and multi-strand flexible copper leads, adhering to superior industry standards for core manufacturing processes. The clamping plates are made of single-piece electrical-grade laminated wood—molded as a solid unit without seams—ensuring high insulation strength. The leads consist of multi-strand flexible copper wire wrapped in insulation; this design offers excellent flexibility and effectively absorbs shocks and vibrations, making it particularly suitable for long-distance transport and navigation over challenging road conditions.

Five key anti-corrosion upgrades ensure suitability for extreme environments: stainless steel bolts eliminate the risk of seizing; a transition from right angles to rounded contours enhances coating adhesion; a three-step pretreatment process (shot blasting, pickling, and phosphating) is employed; and C5-grade electrostatic powder coating (150μm thickness) provides salt spray resistance exceeding 1,000 hours. Additionally, rubber protective sleeves are used during lifting to ensure damage-free delivery.

Product Features

1. Excellent Electrical and Mechanical Performance: Through our proprietary calculation and verification procedures, core components such as the core, coil, and leads are precisely optimized, resulting in products with high electrical and mechanical strength, capable of withstanding severe grid surges and short-circuit currents.

2. Energy-Saving, Environmentally Friendly, and Economically Efficient: The product features low losses (both no-load and loaded) and low noise levels, effectively reducing power station operating costs, complying with national industrial policies for energy conservation and consumption reduction, and enhancing the overall economic benefits of the power grid.

3. Extremely High Operational Reliability: The low partial discharge design and fully sealed, no-hanging core structure effectively prevent moisture and aging of the insulating oil, significantly reducing maintenance workload, extending the equipment life, and ensuring absolute long-term operational reliability.

4. Compact Structure and Superior Design: Superior craftsmanship and material selection ensure the transformer maintains performance while achieving the advantages of small size and light weight, facilitating transportation and installation, and saving space. The winding arrangement (core-low voltage-medium voltage-high voltage) of the step-down three-winding transformer is optimized to optimize impedance distribution and meet system protection requirements.

5. Excellent grid adaptability: One winding in the three-winding design is typically connected in a delta configuration, effectively suppressing third harmonics, improving voltage waveform quality, and ensuring high-standard adaptability to modern power grids.

Wide Application

Due to their stable and reliable performance, the 66kV power transformer is suitable for a variety of harsh environments. Its main applications are:

Traditional power systems: major power plants and regional substations, serving as key nodes for power transmission and distribution.

Urban infrastructure: power supply systems in densely populated areas such as high-rise buildings, commercial centers, subways, airports, and train stations.
Large-scale industrial sectors: industrial and mining enterprises, petrochemical bases, and other locations with extremely high requirements for power supply continuity and safety.
Harsh environments: particularly suitable for offshore drilling platforms, oil production platforms, and special environments such as flammable and explosive environments. Its fully sealed and rugged structure provides extremely high safety assurance.

Our R&D Advantages

TSTY currently has 600 employees and a technical R&D team of over 200 people. It has established a science and technology innovation center to focus on material and process innovation and realize independent research and development of transformers. Relying on the national CNAS certified laboratory, each product passes more than ten rigorous tests such as lightning impulse and insulation no-load loss to ensure stable operation in all environments.

Project Case

Our products are exported to more than 80 countries and regions, serving power projects in various regions.

About TSTY

TSTY Electric Co., Ltd is a national high-tech enterprise with a history of more than 30 years, focusing on the intelligent manufacturing of power transmission and distribution equipment. It mainly deals in oil-immersed, dry-type transformers, box-type substations, high and low voltage switchgear and have obtained ISO 9001, CCC, CE, IEC, GOST and other certifications, 158 patents, and are exported to more than 80 countries.  Factory scale: 250,000 square meters of park, 15 production lines (including 3 intelligent lines), equipped with 220+ intelligent equipment.  Production capacity efficiency: annual output value of 1.5 billion yuan, product qualification rate> 99.8%.
